Edscha TS CS-ECO

The Edscha TS CS-ECO is a low-cost way to fit a side curtain structure with a light, solid tarpaulin roof in standard Edscha TS quality if loading accessibility from above is not necessary.

Advantages

  • Low weight
  • Fast, simple assembly
  • Intelligent material mix with re-inforced metal/plastic structure
Simple assembly by sliding the bows
Simple assembly by sliding the bows
Bow with sliding element
Bow with sliding element

Special features

  • A low-cost alternative to a box structure.
  • Light, proven load cover with tarpaulin.
  • The Edscha TS CS-ECO allows the correct rear closure for every loading situation
  • Low weight
  • Erecting portal beam / end bow
  • Fixed portal beam / end bow
  • Fast and simple assembly
End carriage with erecting portal beam for maximum aperture height
End carriage with erecting portal beam for maximum aperture height
End carriage with erecting end bow for maximum aperture height
End carriage with erecting end bow for maximum aperture height

Equipment options

  • Standard carriage
  • For standard, volume, universal and universal classic roof straps
  • Optional for rail roofs
  • With standard gantry beam or end bow
  • Optional combination with Tailwing
  • Different rear closure variations available
Fixed portal beam
Fixed portal beam
Fixed end bow
Fixed end bow

Downloads

  • Katalog PDF

    Brochure

    Edscha TS CS-ECO

  • User Manual PDF

    User Manual

    Edscha TS CS-ECO

  • Assembly Instructions PDF

    Assembly Instructions

    Edscha TS CS-ECO

  • Repairing Instructions PDF

    Repairing Instructions

    Edscha TS CS-ECO

  •
